Removable bollard TISO RB345-62

Removable bollard TISO RB345-62

TiSO traffic manually retractable bollards is generally used when access to vehicles is more frequent or if a power source is unavailable. As with the other TiSO bollards it is used as a static obstacle to secure pedestrian or other areas from unauthorized vehicle traffic.These bollards are a perfect solution for installations which require temporary free driveways during certain hours of a day/night. The bollard are locked / unlocked by a turn of a specially supplied key.The user-friendly handle at the top of the bollard enables easy and smooth manual rising and lowering. The other advantage is that these bollards do not require a power supply.TiSO range of manually retractable bollards are available in different dimensions, blocking heights, tube materials and diameters.

ModelRB345-62RB345-51RB345-52RB345-65RB345-54RB345-55
Installation typesubmersible
Typemanually / retractable
Tube height, mm600800
Tube diameter, mmØ 140Ø 219Ø 273Ø 140Ø 219Ø 273
Wall thickness, mm4
Overall dimensions (HxLxW), mm
lowered foundation anchors
raised foundation anchors

915х420х460
915x570x610

915х460х608
915x610x755

915х515х685
915x665x830

1115х420х460
1115x570x610

1115х460х608
1115x610x755

1115х515х685
1115x665x830
Operation temperatures**, °C-40/ +60
Retractable TubeConst. steel / Stainless steel
Tube coating (standard)Corrosion-resistant coating +RAL
*Technical data subject to change without notice.
** For temperatures lower than -10° C use the heating device / for temperatures higher than +40° C usethe cooler device
